มาตรวัดอ้างอิง MT680s Portable Test System
Brand : ZERA
Catalog : >Google Drive
Model : MT680s
• ความแม่นยำ: 0.1, Class 0.05
• การสร้างกระแส: 120 A
• จำนวนเฟส: 1
• การวัดกระแสสูงสุด: 120 A (การวัดโดยตรง)
• การวัดแรงดันสูงสุด: 500 V
• หน้าจอ
ขนาด 6.5 / สี
ฟังก์ชันสัมผัส
• ฟังก์ชันหลัก การแสดงค่าจริง, การแสดงเวกเตอร์และกราฟ
การสร้างกระแส การวัดความผิดพลาด
การวัดฮาร์มอนิกส์สูงสุดถึงลำดับที่ 40
การจ่ายแรงดันไฟฟ้าผ่านแรงดันไฟฟ้าที่มีจากกริด
• ขอบเขตการใช้งาน
การวัดภาคสนามพร้อมการจำลองภาระ
การจำลองภาระขณะทดสอบการติดตั้งมิเตอร์ที่ไซต์งาน
• คุณสมบัติพิเศษ
การวัดอัตโนมัติ
อุปกรณ์กะทัดรัด
การวัดพลังงาน (ออฟชัน)
การวัดพลังงานเฉพาะ (ออฟชัน)
หน้าจอสัมผัส
DESCRIPTION
• Accuracy class: 0.1, Class 0.05
• Generation: 120 A
• Phases : 1
• Current measurement max. : 120 A (direct measurement)
• Voltage measurement max. : 500 V
• Display
– 6.5
– Coloured
– Touch function
• Main functions
– Actual values, vectorial and curve display
– Current generation
– Error measurement
– Measurement of harmonics up to the 40th
– Voltage supply via available voltage from the grid
• Scope of application
– On-site measurement with load simulation
– Simulation of load while testing meter installations on-site
• Specials
– Automatic measurement
– Compact device
– Energy dosage (optional)
– Selective power measurement (optional)
– Touch screen
