MT10 เครื่องคาลิเบทมิเตอร์พลังงานซื้อขายไฟฟ้า 1เฟส คลาส 0.1
Catalog : Google Drive
Brand : YONGSUNG
Model : MT10
MT10 เป็นมาตรวัดอ้างอิงที่มีน้ำหนักเบาและกะทัดรัดสำหรับการตรวจสอบและสอบเทียบมาตรวัดไฟฟ้ากระแสสลับชนิดเฟสเดียวในสถานที่
แรงดันทดสอบสำหรับมาตรวัดอ้างอิงแบบกะทัดรัดจะถูกวัดที่แหล่งจ่ายไฟในสถานที่ การวัดกระแสไฟฟ้าต้องทำผ่านแคลมป์วัดกระแส
• ความแม่นยำ: 0.2
• จำนวนเฟส: 1
• การวัดกระแสสูงสุด: 30,000 A (ผ่านแคลมป์วัดกระแสพิเศษ)
• การวัดแรงดันสูงสุด: 300 V
• หน้าจอแสดงผล ขนาด 5.9 นิ้ว ขาวดำ
• ฟังก์ชันหลัก การแสดงค่าจริง, เวกเตอร์ และกราฟ การวัดข้อผิดพลาด การวัดฮาร์มอนิกส์สูงสุดถึงอันดับที่ 40
• ขอบเขตการใช้งาน: การวัดในสถานที่พร้อมกับการโหลดของระบบ
• คุณสมบัติพิเศษ สามารถใช้เป็นอุปกรณ์ประเภท CAT IV การวัดพลังงานแบบเลือกเฉพาะ (ออปชัน)
จ่ายไฟผ่านหน่วยจ่ายไฟภายนอก หรือผ่านแบตเตอรี่ภายในที่ชาร์จได้ (ออปชัน)
DESCRIPTION
MT10 is light weight and Compact Reference Meter for on-site verification and calibration of single phase domestic meters.
Test voltage for the Compact Reference Meter will be measured at the mains on site. Test current must be measured via current clamp
• Accuracy class : 0.2
• Phases : 1
• Current measurement max : 30000 A (via special current clamps)
• Voltage measurement max : 300 V
• Display 5.9 – Monochrome
• Main functions Actual values, vectorial and curve display
– Error measurement
– Measurement of harmonics up to the 40th
• Scope of application : On-site measurement with system load
• Specials
– Also available as CAT IV device
– Selective power measurement (optional)
– Supply via external power supply unit or optional via internal rechargeable battery (optional)
