รีเลย์ตรวจจับอุณหภูมิ Temperature Monitoring Relay SK 9094
Brand : DOLD
Catalog : Google Drive
Model : SK 9094
Size : 17.5 x 90 x 98 mm
• ตามมาตรฐาน IEC/EN 60255-1
• อินพุต PT100 จำนวน 1 ช่อง, การเชื่อมต่อ 2 สาย
• ช่วงอุณหภูมิ 3 ช่วง
• ปรับค่าเกณฑ์การตอบสนองได้
• ปรับความหนืดได้ในช่วงกว้าง 3 … 30 °C หรือ 1 … 15°C
• การตรวจพบสายขาดในวงจรเซ็นเซอร์
• ฟังก์ชันความหนืดหรือการจับค่าที่สามารถตั้งโปรแกรมได้ผ่านขั้ว X1
• การทำงานแบบวงจรปิด
• ไฟ LED แสดงสถานะการทำงานและสถานะของรีเลย์เอาต์พุต
• ช่องติดต่อเปลี่ยนสถานะ 1 ช่อง
• มีตัวเลือกการตั้งค่าเกณฑ์การตอบสนองถึง -50°C เช่น สำหรับระบบทำความเย็น
• มีตัวเลือกการแยกวงจรระหว่างวงจรการวัดและวงจรเสริม
• สามารถติดตั้งบนราง DIN หรือแบบสกรู
• หมายเลขสินค้า: 0051642
• เทอร์โมพลาสติกที่มีพฤติกรรม V0 ตาม UL subject 94
Description
• According to IEC/EN 60255-1
• 1 PT100 input, 2-wire connection
• 3 temperature ranges
• Adjustable response value
• Adjustable Hysteresis with wide range 3 … 30 °C or 1 … 15°C
• Broken wire detection in sensor circuit
• Programmable hysteresis or latching function via terminal X1
• Closed circuit operation
• LED indicator for operation and state of output relay
• 1 changeover contact
• As option with response value up to – 50°C, e.g. for refrigeration plants
• As option with galvanic separation between measuring and Auxiliary Circuit
• DIN rail or screw mounting
• Article number: 0051642
• Thermoplastic with V0 behaviour according to UL subject 94
