Mains Frequency Monitor Varimeter MH 9143
Varimeter ตัวตรวจสอบความถี่ของไฟฟ้า
Brand : DOLD
Catalog : Google Drive
Model : MH 9143
Size : 45 x 90 x 97 mm
• ตามมาตรฐาน IEC / EN 60255-1
• การตรวจสอบการจ่ายกระแส 50 และ 60 Hz สำหรับการเกิดความถี่เกินและความถี่ต่ำ
• การตรวจสอบเครื่องกำเนิดไฟฟ้าและแหล่งจ่ายปกติ
• สำหรับการวัดความถี่ที่แม่นยำด้วยเวลาตอบสนองที่รวดเร็ว
• ความต้านทานการรบกวนสูง
• จุดตั้งค่าการตัดต่อที่ปรับแยกได้และเอาต์พุตแยกสำหรับความถี่เกินและความถี่ต่ำ (1 หรือ 2 ชุดการเปลี่ยนแปลง)
• การหน่วงเวลาเริ่มต้น 0…30 วินาทีสามารถเลือกได้
• การรีเซ็ตด้วยมือหรืออัตโนมัติสามารถเลือกได้
• การเลือกฟังก์ชันการทำงานของรีเลย์เอาต์พุต: การทำงานเมื่อมีการกระตุ้นหรือหยุดทำงานเมื่อเกิดเหตุขัดข้องสำหรับความถี่เกิน
• การหยุดทำงานเมื่อเกิดเหตุขัดข้องสำหรับความถี่ต่ำ
• อินพุตการวัดความถี่แบบยูนิเวอร์แซลสำหรับ AC 40 … 550V
• ตัวเลือกหลายตัวสำหรับแหล่งจ่ายไฟเสริม
• มีออปชันไม่ต้องใช้แหล่งจ่ายไฟเสริมสำหรับช่วงแรงดันไฟฟ้า AC 18 … 70 V หรือ 70 … 275V
• ไฟ LED แสดงสถานะแหล่งจ่ายไฟเสริม, ความถี่อินพุต, สัญญาณเตือนความถี่เกินและความถี่ต่ำ
• หมายเลขสินค้า: 0060936
• ทำจากเทอร์โมพลาสติกที่มีคุณสมบัติ V0 ตามมาตรฐาน UL Subject 94
Description
• According to IEC / EN 60255-1
• Monitoring of 50 – and 60 Hz-current supply on over- and underfrequency
• Monitoring of local generator sets and voltage supplies
• For precise frequency measuring with fast response time
• High disturbance immunity
• Separately adjustable trip points and separate outputs for overand underfrequency (1 or 2 c/o each)
• Start up delay 0…30 s selectable
• Manual or auto reset selectable
• Output relay energized or de-energized on trip selectable for overfrequency
• Output relay de-energized on trip for underfrequency
• Universal frequency measuring input for AC 40 … 550V
• Several options for auxiliary supply
• As option without aux. supply for voltage range AC 18 … 70 V or 70 … 275V
• LED indicators for auxiliary supply, input frequency, over and under frequency alarm
• Article number: 0060936
• Thermoplastic with V0 behaviour according to UL subject 94
