Keep Relay (4P)
Model : YS MMK-4PB110A110D, YS MM-4PC110A110D
Catalog : Google Drive
Brand : YONGSUNG
Size : 80 x 73 x 122 mm, 80 x 73 x 84 mm
• เก็บรีเลย์ด้วยวิธีการล็อคเครื่องกล (ประเภท MMK)
• เนื่องจากการทำงานของเครื่องจักรจึงประหยัดการใช้พลังงานน้อยลง (MMK)
• เป็นไปได้ที่จะจ่ายรีเลย์ด้วยขดลวดชุด AC และขดลวดรีเซ็ต DC (MMK)
• การตอบสนองอย่างรวดเร็วเนื่องจากกำลังสัญญาณชีพจร
• ความน่าเชื่อถือในการติดต่อที่มั่นคงและอายุการใช้งานที่ยาวนาน
• การตั้งค่าและการเชื่อมต่อที่ง่ายและการบำรุงรักษาที่ง่าย
• ประเภท MM กำลังถือรีเลย์อยู่
• ทนแรงดันไฟฟ้า: AC 2,000V/นาที
• อุณหภูมิแวดล้อม: -25’c – +40’C
• ความชื้นสัมพัทธ์ : 45 – 85%
• ความต้านทานการฉนวน: เหนือ 100MQ DC 500V เม็ก
• โพลีคาร์บอเนตเรซิน
DESCRIPTION
• Keep relay with mechanical lock method, (MMK type)
• Due to being mechanically operated, it is economical with less power consumption. (MMK)
• Possible to supply relay with AC set coil and DC reset coil also possible. (MMK)
• Rapid reponse due to pulse signal power.
• Stabilized contact reliability and long lifetime.
• Easy setting and wiring and simple maintenance.
• MM type is holding relay.
• Withstand voltage : AC 2,000V/min
• Ambient temperature : -25’c – +40’C
• Relative humidity : 45 – 85%
• Insulation resistance : Above 100MQ DC 500V. Meg
• Polycarbonate resin
